The LM5576MHX/NOPB is a DC/DC controller with an adjustable output voltage of 70V and a maximum output current of 3A. It operates over a temperature range of -40°C to 125°C and is packaged in a HTSSOP EP package. The device is RoHS compliant and has a quiescent current of 1mA. It is designed for use in power management applications and is part of the PowerWise and SIMPLE SWITCHER series.
PackageHTSSOP EP
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments LM5576MHX/NOPB technical specifications.
General
| Package/Case | HTSSOP EP |
| Efficiency | 90% |
| Lead Free | Lead Free |
| Max Input Voltage | 75V |
| Min Input Voltage | 6V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 3A |
| Max Output Voltage | 70V |
| Min Output Voltage | 1.225V |
| Min Supply Voltage | 6V |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Operating Supply Voltage | 75V |
| Output Current | 3A |
| Output Type | Adjustable |
| Output Voltage | 70V |
| Packaging | Tape and Reel |
| Quiescent Current | 1mA |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | PowerWise®, SIMPLE SWITCHER® |
| Synchronous Rectifier | No |
Compliance
| RoHS | Compliant |
Datasheet
Texas Instruments LM5576MHX/NOPB Datasheet
Download the complete datasheet for Texas Instruments LM5576MHX/NOPB to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
