The LM723H/883 is a linear voltage regulator with adjustable output voltage. It has a maximum output current of 150mA and a maximum power dissipation of 800mW. The device is packaged in a TO-100 package and is available in a tray. The LM723H/883 is not RoHS compliant and contains lead, making it a non-lead-free device. It operates within a temperature range and has a quiescent current of 400uA.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments LM723H/883 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | TO-100 |
| Dropout Voltage | 40mV |
| Lead Free | Contains Lead |
| Max Input Voltage | 40V |
| Min Input Voltage | 9.5V |
| Max Output Current | 150mA |
| Max Power Dissipation | 800mW |
| Mount | Through Hole |
| Number of Outputs | 1 |
| Output Current | 150mA |
| Output Type | Adjustable |
| Output Voltage | 37V |
| Packaging | Tray |
| Polarity | Positive |
| Power Dissipation | 800mW |
| Quiescent Current | 400uA |
| Reference Voltage | 7.35V |
| RoHS Compliant | No |
| RoHS | Not Compliant |
