Digital temperature sensor with SPI interface, offering 12-bit resolution and ±1.25°C accuracy. Features a wide operating temperature range from -40°C to 125°C and a supply voltage range of 3V to 3.6V (max 5.5V). This surface-mount component is housed in an 8-SOIC package with dimensions of 4.9mm (L) x 3.9mm (W) x 1.45mm (H). RoHS compliant with a typical supply current of 310µA.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments LM74CIM-3/NOPB datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SOIC |
| Height | 1.45mm |
| Interface | SPI |
| Lead Free | Lead Free |
| Length | 4.9mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage (DC) | 3.6V |
| Min Supply Voltage (DC) | 3V |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 3V |
| Mount | Surface Mount |
| Number of Bits | 13 |
| Output Type | SPI, Digital |
| Output Voltage | 2.4V |
| Packaging | Rail/Tube |
| Quiescent Current | 520uA |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Resolution | 12b |
| RoHS Compliant | Yes |
| Supply Current | 310uA |
| Termination | SMD/SMT |
| Width | 3.9mm |
| RoHS | Compliant |
Download the complete datasheet for Texas Instruments LM74CIM-3/NOPB to view detailed technical specifications.
