The PCM1716E/2K is a 24-bit dual digital-to-analog converter with a conversion rate of 96 kilosamples per second. It operates from a 4.5 to 5.5-volt supply voltage and is packaged in a lead-free SSOP-28 package. The device is RoHS compliant and has a signal-to-noise ratio of 106 decibels. It is designed for surface mount applications and has a maximum operating temperature of 85 degrees Celsius. The PCM1716E/2K is a member of the PCM1716 series of data converters.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments PCM1716E/2K datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments PCM1716E/2K technical specifications.
| Package/Case | SSOP |
| Conversion Rate | 96KS/s |
| Interface | Serial, 3-WIRE |
| Lead Free | Lead Free |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -25°C |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Number of Bits | 24 |
| Number of Channels | 2 |
| Number of Converters | 2 |
| Operating Supply Voltage | 5V |
| Output Type | Voltage |
| Package Quantity | 2000 |
| Packaging | Tape and Reel |
| Resolution | 24b |
| RoHS Compliant | Yes |
| Series | PCM1716 |
| Signal to Noise Ratio (SNR) | 106dB |
| Weight | 0.010229oz |
| RoHS | Compliant |
