7-port Multidrop IEEE 1149.1 (JTAG) Multiplexer, this integrated circuit features a 100-NFBGA package for surface mounting. It supports serial and parallel interfaces with a maximum input voltage of 3.6V and a supply voltage range of 3V to 3.6V. Operating across a temperature range of -40°C to 85°C, it offers a maximum output current of 24mA and a maximum output voltage of 2.4V. This RoHS compliant component is supplied in trays and is lead-free.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments SCANSTA112SM/NOPB datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | FBGA |
| Interface | Serial, Parallel |
| Lead Free | Lead Free |
| Max Input Voltage | 3.6V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 24mA |
| Max Output Voltage | 2.4V |
| Max Supply Voltage | 3.6V |
| Min Supply Voltage | 3V |
| Mount | Surface Mount |
| Packaging | Tray |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Termination | SMD/SMT |
| RoHS | Compliant |
