8-bit parallel-out serial shift register, featuring CMOS technology and a unidirectional data flow. This surface-mount component operates with a supply voltage range of 2V to 6V, typically 5V, and offers 8 parallel outputs with push-pull configuration. It boasts a maximum operating temperature of 125°C and a minimum of -40°C, with a propagation delay of 30ns. Packaged in a 14-TSSOP, this RoHS compliant IC is designed for efficient serial-to-parallel data conversion.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments SN74HC164PW datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments SN74HC164PW technical specifications.
| Package/Case | TSSOP |
| Direction | Unidirectional |
| Lead Free | Lead Free |
| Logic Function | Shift Register |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 6V |
| Min Supply Voltage | 2V |
| Mount | Surface Mount |
| Number of Bits | 8 |
| Number of Bits per Element | 8 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Input Lines | 2 |
| Number of Output Lines | 8 |
| Operating Supply Voltage | 5V |
| Output Type | PUSH-PULL |
| Package Quantity | 90 |
| Packaging | Rail/Tube |
| Propagation Delay | 30ns |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | 74HC |
| Technology | CMOS |
| Turn-On Delay Time | 255ns |
| Weight | 0.002018oz |
| RoHS | Compliant |
