8-bit shift register with 3-state output, featuring CMOS technology and a unidirectional data flow. This surface-mount component operates from a 2V to 5.5V supply voltage, with a typical operating voltage of 5V. It offers 9 output lines and a maximum propagation delay of 10.2ns. Designed for a wide temperature range of -40°C to 125°C, this RoHS-compliant integrated circuit is packaged in a 16-SOIC format on tape and reel.
PackageSOIC
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments SN74LV595ADRG4 technical specifications.
General
| Package/Case | SOIC |
| Direction | Unidirectional |
| Lead Free | Lead Free |
| Logic Function | Shift Register |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 2V |
| Mount | Surface Mount |
| Number of Bits | 8 |
| Number of Bits per Element | 8 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Input Lines | 1 |
| Number of Output Lines | 9 |
| Number of Outputs | 9 |
| Operating Supply Voltage | 5V |
| Output Type | 3-STATE |
| Package Quantity | 2500 |
| Packaging | Tape and Reel |
| Propagation Delay | 10.2ns |
| RoHS Compliant | Yes |
| Series | 74LV |
| Technology | CMOS |
| Turn-On Delay Time | 25.5ns |
| Weight | 0.004998oz |
Compliance
| RoHS | Compliant |
Datasheet
Texas Instruments SN74LV595ADRG4 Datasheet
Download the complete datasheet for Texas Instruments SN74LV595ADRG4 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
