The THS9001DBVR is a single-channel RF amplifier from Texas Instruments, packaged in a SOT-23-6 case. It operates within a temperature range of -40°C to 85°C and has a maximum power dissipation of 463mW. The amplifier is designed to handle frequencies up to 350MHz and has a gain of 15dB. It is lead-free and RoHS compliant, making it suitable for a variety of applications.
Sign in to ask questions about the Texas Instruments THS9001DBVR datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments THS9001DBVR technical specifications.
| Package/Case | SOT-23-6 |
| Frequency | 350MHz |
| Gain | 15dB |
| Lead Free | Lead Free |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 463mW |
| Noise Figure | 4.5dB |
| Number of Channels | 1 |
| Operating Frequency | 350 MHz |
| Operating Supply Current | 100mA |
| Operating Supply Voltage | 3V |
| P1dB | 20.6dBm |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Supply Current | 100mA |
| Test Frequency | 350MHz |
| Weight | 0.000353oz |
| RoHS | Compliant |
