Texas Instruments
TLE2022AMFKB
Dual-Channel Operational Amplifier LCC-20 Package, 1.7MHz Gain Bandwidth
The TLE2022AMFKB is a dual-channel operational amplifier from Texas Instruments, packaged in a 20-pin LCC package. It features a common mode rejection ratio of 87dB and a gain bandwidth product of 1.7MHz. The amplifier has an input bias current of 70nA and is capable of operating over a temperature range of -55°C to 125°C. It is not RoHS compliant and contains lead, making it non-compliant with lead-free regulations.
PackageLCC
Quick Jump:
Technical Specifications
Texas Instruments TLE2022AMFKB technical specifications.
General
| Package/Case | LCC |
| Common Mode Rejection Ratio | 87dB |
| Gain Bandwidth Product | 1.7MHz |
| Input Bias Current | 70nA |
| Lead Free | Contains Lead |
| Max Dual Supply Voltage | 20V |
| Min Dual Supply Voltage | 2V |
| Max I/O Voltage | 400uV |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Supply Voltage | 40V |
| Min Supply Voltage | 4V |
| Nominal Gain Bandwidth Product | 1.7MHz |
| Number of Channels | 2 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| RoHS Compliant | No |
| Slew Rate | 0.5V/µs |
| Voltage Gain | 123.52dB |
Compliance
| RoHS | Not CompliantNo |
