Texas Instruments
TLV431AQDBVRQ1
Automotive, low-voltage adjustable precision shunt regulator 5-SOT-23 -40 to 125
PackageSOT-23-5
Quick Jump:
Technical Specifications
Texas Instruments TLV431AQDBVRQ1 technical specifications.
General
| Package/Case | SOT-23-5 |
| Cathode Current | 100uA |
| Height | 1.45mm |
| Lead Free | Lead Free |
| Length | 2.9mm |
| Max Input Voltage | 7V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 15mA |
| Max Output Voltage | 6V |
| Number of Channels | 1 |
| Output Current | 15mA |
| Output Voltage | 6V |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Reference Type | Shunt, Adjustable |
| RoHS Compliant | Yes |
| Thickness | 1.2mm |
| Tolerance | 1% |
| Width | 1.6mm |
Compliance
| RoHS | Compliant |
Datasheet
Texas Instruments TLV431AQDBVRQ1 Datasheet
Download the complete datasheet for Texas Instruments TLV431AQDBVRQ1 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
