Texas Instruments
TPA0212PWPRG4
Stereo Class-AB Audio Amplifier with Stereo Headphone Drive and Integrated Gain 24-HTSSOP -40 to 85
PackageHTSSOP
Current8mA
Power2W
Quick Jump:
Technical Specifications
Texas Instruments TPA0212PWPRG4 technical specifications.
General
Package/Case
HTSSOP
Lead Free
Lead Free
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Output Power
2.6W
Max Power Dissipation
2.7W
Max Supply Voltage
5.5V
Min Supply Voltage
4.5V
Number of Channels
2
Operating Supply Voltage
5V
Output Power
2W
Package Quantity
2000
Packaging
Tape and Reel
Power Dissipation
2.7W
Power Supply Rejection Ratio (PSRR)
77dB
Quiescent Current
6mA
Radiation Hardening
No
RoHS Compliant
Yes
Series
TPA0212
Supply Current
8mA
Supply Type
Single
Weight
0.00346oz
Compliance
RoHS
Compliant
Datasheet
Texas Instruments TPA0212PWPRG4 Datasheet
Download the complete datasheet for Texas Instruments TPA0212PWPRG4 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
