TPS2419PW

Datasheet

Single Channel OR Controller, 1.2mA Quiescent Current, 250mW Power Dissipation, TSSOP Package

Texas Instruments

TPS2419PW

Name: TPS2419PW Texas Instruments
Brand: Texas Instruments
SKU: TPS2419PW

Active

Single Channel OR Controller, 1.2mA Quiescent Current, 250mW Power Dissipation, TSSOP Package

The TPS2419PW is a single-channel OR controller from Texas Instruments. It operates within a temperature range of -40°C to 85°C and has a maximum supply voltage of 16.5V. The device is packaged in a lead-free TSSOP package with a height of 1mm and a length of 3.1mm. It is RoHS compliant and has a quiescent current of 1.2mA. The TPS2419PW is suitable for use in applications where a low-power OR controller is required.

PackageTSSOP

Power250mW

Quick Jump:

Pricing & Availability

Checking distributor stock and pricing after the page loads.

Chat with Datasheet

Technical Specifications

General

Package/Case	TSSOP
Height	1mm
Lead Free	Lead Free
Length	3.1mm
Max Input Voltage	16.5V
Min Input Voltage	800mV
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
Max Supply Voltage	16.5V
Min Supply Voltage	800mV
Number of Channels	1
Number of Outputs	1
Package Quantity	150
Packaging	Rail/Tube
Power Dissipation	250mW
Quiescent Current	1.2mA
Radiation Hardening	No
Reach SVHC Compliant	No
RoHS Compliant	Yes
Turn-Off Delay Time	70ns
