300mA, adjustable output buck converter with 3V to 17V input range. Features include a 1.2V to 10V output voltage capability, 13µA quiescent current, and synchronous rectification. This surface mount component operates from -40°C to 85°C and is packaged on tape and reel. Its compact 2.1mm x 2.1mm x 0.75mm dimensions make it suitable for space-constrained applications.
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments TPS62125DSGT technical specifications.
General
Height
0.75mm
Lead Free
Lead Free
Length
2.1mm
Max Input Voltage
17V
Min Input Voltage
3V
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Output Current
300mA
Max Output Voltage
10V
Min Output Voltage
1.2V
Mount
Surface Mount
Number of Outputs
1
Operating Supply Current
13uA
Output Current
300mA
Output Type
Adjustable
Output Voltage
10V
Package Quantity
1
Packaging
Tape and Reel
Quiescent Current
13uA
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
DCS-Control™
Synchronous Rectifier
Yes
Weight
0.000384oz
Width
2.1mm
Compliance
RoHS
Compliant
Datasheet
Texas Instruments TPS62125DSGT Datasheet
Download the complete datasheet for Texas Instruments TPS62125DSGT to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
