Power Management IC featuring I2C interface, operating from 2.5V to 6V input and delivering up to 6V output. This surface mount component offers 1.5A output current with a 2.25MHz switching frequency and 85µA quiescent current. Designed for reliable operation, it includes over-temperature fault protection and is RoHS compliant. The 40-pin WQFN EP package measures 5mm x 5mm x 0.75mm.
Frequency2.25MHz
PackageQFN
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments TPS65023RSBT technical specifications.
General
| Package/Case | QFN |
| Fault Protection | Over Temperature |
| Frequency | 2.25MHz |
| Height | 0.75mm |
| Interface | I2C |
| Lead Free | Lead Free |
| Length | 5mm |
| Max Input Voltage | 6V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Output Voltage | 6V |
| Max Supply Voltage | 6V |
| Min Supply Voltage | 2.5V |
| Mount | Surface Mount |
| Number of Cells | 1 |
| Output Current | 1.5A |
| Output Voltage | 6V |
| Package Quantity | 250 |
| Packaging | Tape and Reel |
| Quiescent Current | 85uA |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Termination | SMD/SMT |
| Thickness | 750um |
| Weight | 0.001929oz |
| Width | 5mm |
