Texas Instruments
TPS75100DSKR
Low Dropout, Two-Bank LED driver with PWM brightness control with 10mA/ch 10-SON -40 to 85
PackageSON
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments TPS75100DSKR technical specifications.
General
| Package/Case | SON |
| Dimming | PWM |
| Lead Free | Lead Free |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.5V |
| Mount | Surface Mount |
| Number of Channels | 4 |
| Number of Outputs | 4 |
| Output Current per Channel | 25mA |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Quiescent Current | 180uA |
| RoHS Compliant | Yes |
Compliance
| RoHS | Compliant |
Datasheet
Texas Instruments TPS75100DSKR Datasheet
Download the complete datasheet for Texas Instruments TPS75100DSKR to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
