Automotive 5V, 150mA low-dropout linear voltage regulator with 1% accuracy. Features a 40V maximum input voltage, 300mV dropout voltage, and a low quiescent current of 12µA. Operates across a wide temperature range of -40°C to 125°C, suitable for automotive applications. Packaged in an 8-pin HVSSOP for surface mounting, this RoHS compliant component offers a power good output.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments TPS7A6650QDGNRQ1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Texas Instruments TPS7A6650QDGNRQ1 technical specifications.
| Accuracy | 1% |
| Package/Case | MSOP |
| Dropout Voltage | 300mV |
| Lead Free | Lead Free |
| Max Input Voltage | 40V |
| Min Input Voltage | 4V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 150mA |
| Mount | Surface Mount |
| Nominal Output Voltage | 5V |
| Number of Outputs | 1 |
| Number of Regulators | 1 |
| Operating Supply Current | 12uA |
| Output Current | 150mA |
| Output Type | Fixed, Adjustable |
| Output Voltage | 5V |
| Package Quantity | 2500 |
| Packaging | Tape and Reel |
| Polarity | Positive |
| Power Supply Rejection Ratio (PSRR) | 60dB |
| Quiescent Current | 20uA |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | Automotive, AEC-Q100 |
| Weight | 0.000649oz |
| RoHS | Compliant |
