Dual differential line receiver IC featuring two receivers and two drivers, operating at a 10Mbps data rate. This integrated circuit supports a 5V operating supply voltage (4.75V to 5.25V) and is housed in an 8-PDIP package with dimensions of 10.16mm length, 6.6mm width, and 4.57mm height. It offers a 50mA output current and 1.1mA input current, with a power dissipation of 1W. The component operates within a temperature range of 0°C to 70°C and is RoHS compliant.
PackageP
Current50mA
Power1W
Quick Jump:
Technical Specifications
Texas Instruments UA9639CP technical specifications.
General
Package/Case
P
Data Rate
10Mbps
Height
4.57mm
Input Current
1.1mA
Lead Free
Lead Free
Length
10.16mm
Logic Function
Receiver
Max Operating Temperature
70°C
Min Operating Temperature
0°C
Max Supply Voltage
5.25V
Min Supply Voltage
4.75V
Number of Drivers
2
Number of Receivers
2
Operating Supply Current
50mA
Operating Supply Voltage
5V
Output Current
50mA
Package Quantity
50
Packaging
Rail/Tube
Power Dissipation
1W
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Supply Current
50mA
Weight
0.015535oz
Width
6.6mm
Compliance
RoHS
Compliant
Datasheet
Texas Instruments UA9639CP Datasheet
Download the complete datasheet for Texas Instruments UA9639CP to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
