The UC3856N is a dual output DC/DC controller IC with a maximum supply voltage of 40V and a minimum supply voltage of 8V. It operates within a temperature range of 0 to 70°C. The device is packaged in a DIP-16 package and is RoHS compliant. The UC3856N is a flyback and push-pull topology IC with a maximum output current of 1.5A and an output voltage of 13.1V. It has a maximum frequency of 1MHz and a maximum duty cycle of 50%.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments UC3856N datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | N |
| Duty Cycle | 50% |
| Fall Time | 40ns |
| Frequency | 1MHz |
| Lead Free | Lead Free |
| Max Duty Cycle | 50% |
| Max Frequency | 1MHz |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Power Dissipation | 1W |
| Max Supply Voltage | 40V |
| Min Supply Voltage | 8V |
| Number of Outputs | 2 |
| Output Current | 1.5A |
| Output Voltage | 13.1V |
| Package Quantity | 25 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Topology | Flyback, Push-Pull |
| Weight | 0.037172oz |
| RoHS | Compliant |
Download the complete datasheet for Texas Instruments UC3856N to view detailed technical specifications.
