Power Transformers 25.2V CT 2.8A XFMR PRI 115VAC
Sign in to ask questions about the Triad Magnetics F-56X datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Triad Magnetics F-56X technical specifications.
| Current Rating | 2.8A |
| Height - Seated (Max) | 65.15mm |
| Lead Free | Lead Free |
| Length | 101.6mm |
| Max Output Current | 2.8A |
| Mount | Chassis Mount, Flanges, Chassis |
| Output Current | 2.8A |
| Output Voltage | 25.2V |
| Package Quantity | 8 |
| Primary Winding(s) | Single |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Secondary Winding(s) | Single |
| Series | Single Secondary |
| Termination | Wire Leads |
| Weight | 2.5lb |
| Width | 63.5mm |
| RoHS | Compliant |
