Diffuse photoelectric sensor with NPN output, featuring a 6.35mm sensing distance. This through-hole mount component operates with a 1.5V supply voltage and a maximum collector current of 25mA. It offers a collector-emitter breakdown voltage of 15V and a reverse voltage of 3V. The sensor is housed in a TO-46 plastic package, is RoHS compliant, and operates within a temperature range of 0°C to 70°C.
PackageTO-46
MountingThrough Hole
PolarityNPN
Power150mW
Quick Jump:
Technical Specifications
TT OPB730F technical specifications.
General
| Package/Case | TO-46 |
| Collector Emitter Breakdown Voltage | 15V |
| Collector Emitter Voltage (VCEO) | 15V |
| Collector-emitter Voltage-Max | 15V |
| Forward Current | 50mA |
| Input Current | 50mA |
| Lead Free | Lead Free |
| Max Breakdown Voltage | 15V |
| Max Collector Current | 25mA |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Mount | Through Hole |
| Number of Elements | 1 |
| Operating Supply Voltage | 1.5V |
| Package Quantity | 25 |
| Packaging | Bulk |
| Polarity | NPN |
| Power Dissipation | 150mW |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Reverse Breakdown Voltage | 3V |
| Reverse Voltage | 3V |
| Reverse Voltage (DC) | 3V |
| RoHS Compliant | Yes |
| Sensing Distance | 6.35mm |
| DC Rated Voltage | 15V |
| Wavelength | 935nm |
Compliance
| RoHS | Compliant |
Datasheet
TT OPB730F Datasheet
Download the complete datasheet for TT OPB730F to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
