Vishay
293D156X0020B2TE3
Cap Tant Solid 15uF 20V B CASE 20% (3.5 X 2.8 X 1.9mm) Inward L SMD 3528-21 2.3 Ohm 125°C T/R
Package1411
Capacitance15uF
Voltage Rating20V
MountingSurface Mount
Quick Jump:
Technical Specifications
Vishay 293D156X0020B2TE3 technical specifications.
General
| Capacitance | 15uF |
| Package/Case | 1411 |
| Construction | Flat |
| Depth | 2.8mm |
| Dielectric Material | Tantalum |
| ESR (Equivalent Series Resistance) | 2.3R |
| Features | General Purpose |
| Height | 1.9mm |
| Lead Free | Lead Free |
| Length | 3.5mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | TANTAMOUNT®, 293D |
| Tolerance | 20% |
| Voltage Rating | 20V |
| DC Rated Voltage | 2V |
Compliance
| RoHS | Compliant |
Datasheet
Vishay 293D156X0020B2TE3 Datasheet
Download the complete datasheet for Vishay 293D156X0020B2TE3 to view detailed technical specifications.
No datasheet is available for this part.
