Single pole double throw (SPDT) analog switch, featuring a 1-channel, 1-circuit configuration with 1 input and 2 outputs. Operates with single or dual supply voltages from 7V to 22V, with a typical operating voltage of 15V. Offers a low drain-to-source resistance of 20 Ohms and a maximum power dissipation of 400mW. Packaged in a lead-free, RoHS-compliant SOIC case for surface mounting, with dimensions of 5mm length, 4mm width, and 1.55mm height.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Vishay DG419DY-E3 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Vishay DG419DY-E3 technical specifications.
| Package/Case | SOIC |
| Drain to Source Resistance | 20R |
| Dual Supply Voltage | 15V |
| Height | 1.55mm |
| High Level Output Current | 30mA |
| Lead Free | Lead Free |
| Length | 5mm |
| Max Dual Supply Voltage | 22V |
| Min Dual Supply Voltage | 7V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 400mW |
| Max Supply Current | 1uA |
| Max Supply Voltage | 36V |
| Min Supply Voltage | 13V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Inputs | 1 |
| Number of Outputs | 2 |
| Operating Supply Current | 1nA |
| Operating Supply Voltage | 15V |
| Package Quantity | 500 |
| Packaging | Rail/Tube |
| Polarity | Non-Inverting |
| Power Dissipation | 400mW |
| Propagation Delay | 175ns |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Supply Current | 1nA |
| Supply Type | Single, Dual |
| Throw Configuration | SPDT |
| Turn-Off Delay Time | 40ns |
| Turn-On Delay Time | 100ns |
| Weight | 0.019048oz |
| Width | 4mm |
| RoHS | Compliant |
