Technical Specifications
Vishay LTH-209-01 technical specifications.
General
Collector Emitter Breakdown Voltage
30V
Collector Emitter Voltage (VCEO)
30V
Collector-emitter Voltage-Max
30V
Fall Time
4us
Forward Current
20mA
Max Collector Current
20mA
Max Operating Temperature
85°C
Min Operating Temperature
-25°C
Mount
Through Hole
Number of Elements
1
Output Type
Phototransistor
Package Quantity
250
Packaging
Bulk
Power Dissipation
100mW
Reverse Breakdown Voltage
5V
Reverse Voltage
5V
RoHS Compliant
Yes
Sensing Distance
3.81mm
Compliance
RoHS
Compliant
Datasheet
Vishay LTH-209-01 Datasheet
Download the complete datasheet for Vishay LTH-209-01 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
