The LTH-301-32 is a phototransistor sensor with a collector-emitter breakdown voltage of 30V and a maximum collector current of 20mA. It has a response time of 4us and a power dissipation of 100mW. The device is RoHS compliant and has a maximum operating temperature of 85°C. It is available in a through-hole package and is suitable for use in applications where a phototransistor sensor is required.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Vishay LTH-301-32 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Vishay LTH-301-32 technical specifications.
| Collector Emitter Breakdown Voltage | 30V |
| Collector-emitter Voltage-Max | 30V |
| Fall Time | 4us |
| Forward Current | 20mA |
| Lead Free | Lead Free |
| Max Collector Current | 20mA |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -25°C |
| Mount | Through Hole |
| Output Configuration | Phototransistor |
| Package Quantity | 250 |
| Packaging | Bulk |
| Power Dissipation | 100mW |
| Radiation Hardening | No |
| Response Time | 4us |
| RoHS Compliant | Yes |
| Sensing Distance | 15mm |
| RoHS | Compliant |
