Vishay
NTCLE100E3683JB0
RESISTOR, TEMPERATURE DEPENDENT, NTC, 68000 ohm, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT
PackageRadial
Resistance68kR
MountingThrough Hole
Quick Jump:
Technical Specifications
Vishay NTCLE100E3683JB0 technical specifications.
General
Accuracy
1.5%
Package/Case
Radial
Depth
3mm
Height
6mm
Lead Diameter
0.6mm
Lead Free
Lead Free
Lead Pitch
2.54mm
Length
3.3mm
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Power Dissipation
500mW
Mount
Through Hole
Package Quantity
1500
Packaging
Bulk
Radiation Hardening
No
Resistance
68kR
Resistance Tolerance
5%
RoHS Compliant
Yes
Termination
Radial
Tolerance
5%
Width
3mm
Compliance
RoHS
Compliant
Datasheet
Vishay NTCLE100E3683JB0 Datasheet
Download the complete datasheet for Vishay NTCLE100E3683JB0 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
