N-Channel MOSFET, TrenchFET® series, featuring 30V Drain-to-Source Voltage (Vdss) and 1.5A Continuous Drain Current (ID). Surface mount SOT-323 package with 132mR maximum Drain-to-Source On Resistance (Rds On). Offers fast switching with 2ns Turn-On Delay Time and 8ns Fall Time. Operates across a wide temperature range from -55°C to 150°C, with 500mW maximum power dissipation.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Vishay SI1308EDL-T1-GE3 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SOT-323 |
| Continuous Drain Current (ID) | 1.5A |
| Drain to Source Resistance | 132mR |
| Drain to Source Voltage (Vdss) | 30V |
| Drain-source On Resistance-Max | 132mR |
| Fall Time | 8ns |
| Gate to Source Voltage (Vgs) | 12V |
| Height | 1mm |
| Input Capacitance | 105pF |
| Lead Free | Lead Free |
| Length | 2.2mm |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Power Dissipation | 500mW |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Polarity | N-CHANNEL |
| Radiation Hardening | No |
| Rds On Max | 132mR |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | TrenchFET® |
| Threshold Voltage | 600mV |
| Turn-Off Delay Time | 8ns |
| Turn-On Delay Time | 2ns |
| Weight | 0.004395oz |
| Width | 1.35mm |
| RoHS | Compliant |
