N-channel MOSFET transistor featuring a 30V drain-to-source breakdown voltage and 20A continuous drain current. Offers a low 5.1mΩ Rds On at a 10V gate-to-source voltage, with a 1.1V threshold voltage. Designed for surface mounting with a 31.2W power dissipation and operating temperature range of -55°C to 150°C. Includes fast switching characteristics with turn-on delay of 15ns and fall time of 16ns.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Vishay SIRA14DP-T1-GE3 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Vishay SIRA14DP-T1-GE3 technical specifications.
| Continuous Drain Current (ID) | 20A |
| Drain to Source Breakdown Voltage | 30V |
| Drain to Source Resistance | 5.1mR |
| Drain to Source Voltage (Vdss) | 30V |
| Fall Time | 16ns |
| Gate to Source Voltage (Vgs) | 2.2V |
| Height | 0.042inch |
| Input Capacitance | 1.45nF |
| Length | 0.235inch |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Power Dissipation | 31.2W |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Polarity | N-CHANNEL |
| Polarization | N |
| Power Dissipation | 31.2W |
| Radiation Hardening | No |
| Rds On Max | 5.1mR |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | TrenchFET® |
| Threshold Voltage | 1.1V |
| Turn-Off Delay Time | 18ns |
| Turn-On Delay Time | 15ns |
| Weight | 0.01787oz |
| Width | 0.197inch |
| RoHS | Compliant |
