Surface mount tantalum capacitor with 68µF capacitance and 4V DC rating. Features 20% tolerance, 500mΩ ESR, and 10% dissipation factor. Operating temperature range from -55°C to 105°C. Housed in a 1206 (3216 metric) case code, this general-purpose component is lead-free and RoHS compliant, supplied on tape and reel.
Package1206
Capacitance68uF
Voltage Rating4V
MountingSurface Mount
Quick Jump:
Technical Specifications
Vishay T55A686M004C0500 technical specifications.
General
Capacitance
68uF
Case Code (Imperial)
1206
Case Code (Metric)
3216
Package/Case
1206
Construction
Flat
Dissipation Factor
10%
ESR (Equivalent Series Resistance)
500mR
Features
General Purpose
Height
1.6mm
Height - Seated (Max)
0.071inch
Lead Free
Lead Free
Leakage Current
27.2uA
Length
3.2mm
Max Operating Temperature
105°C
Min Operating Temperature
-55°C
Mount
Surface Mount
Packaging
Tape and Reel
Ripple Current
480mA
RoHS Compliant
Yes
Series
vPolyTan™ T55
Termination
SMD/SMT
Tolerance
20%
Voltage Rating
4V
DC Rated Voltage
4V
Width
0.063inch
Compliance
RoHS
Compliant
Datasheet
Vishay T55A686M004C0500 Datasheet
Download the complete datasheet for Vishay T55A686M004C0500 to view detailed technical specifications.
No datasheet is available for this part.
Product Images
