Technical Specifications
Vishay T83E106K050EZZS technical specifications.
General
| Capacitance | 10uF |
| Case Code (Imperial) | 2917 |
| Case Code (Metric) | 7343 |
| Package/Case | 2917 |
| Dissipation Factor | 6% |
| ESR (Equivalent Series Resistance) | 800mR |
| Leakage Current | 5uA |
| Length | 7.3mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Packaging | Tape and Reel |
| Ratings | COTS |
| RoHS Compliant | No |
| Series | TANTAMOUNT®, T83 |
| Termination | SMD/SMT |
| Tolerance | 10% |
| Voltage Rating | 50V |
| DC Rated Voltage | 50V |
| Weight | 0.016861oz |
| Width | 4.3mm |
Compliance
| RoHS | Not Compliant |
Datasheet
Vishay T83E106K050EZZS Datasheet
Download the complete datasheet for Vishay T83E106K050EZZS to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
