Surface mount wirewound RF chip inductor with 43nH inductance and 5% tolerance. Features a ceramic core, 25 Q-factor, and 250MHz test frequency. Rated for 100mA maximum DC current with 810mΩ DC resistance. Operates across a -40°C to 125°C temperature range. Packaged in a 0402 (1005 metric) case.
Frequency250MHz
Package0402
Resistance810mR
Current Rating100mA
Quick Jump:
Technical Specifications
Wurth Electronics 744765143A technical specifications.
General
Case Code (Imperial)
0402
Case Code (Metric)
1005
Package/Case
0402
Core Material
Ceramic
Current Rating
100mA
DC Resistance (DCR)
810mR
Depth
0.55mm
Frequency
250MHz
Height
0.5mm
Height - Seated (Max)
0.024inch
Inductance
43nH
Inductance Tolerance
5%
Length
1mm
Material
Ceramic
Max DC Current
100mA
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Mount
Surface Mount
Package Quantity
1
Packaging
Cut Tape
Q Factor
25
Reach SVHC Compliant
Unknown
Resistance
810mR
RoHS Compliant
Yes
Sample Rate (Hz)
250MHz
Self Resonant Frequency
2.03GHz
Series
WE-KI
Series Resistance
810mR
Shielding
Unshielded
Termination
SMD/SMT
Test Frequency
250MHz
Tolerance
5%
Weight
2.3E-05oz
Width
0.55mm
Compliance
RoHS
Compliant
Datasheet
Wurth Electronics 744765143A Datasheet
Download the complete datasheet for Wurth Electronics 744765143A to view detailed technical specifications.
