XP POWER

LDU4860S300-WD

Datasheet

300mA CC/CV LED Power Supply, 17W, 7-60VDC In, 57VDC Out, Analog/PWM Dim

XP Power

LDU4860S300-WD

Name: LDU4860S300-WD XP Power
Brand: XP Power
SKU: LDU4860S300-WD

300mA CC/CV LED Power Supply, 17W, 7-60VDC In, 57VDC Out, Analog/PWM Dim

17W DC/DC LED power supply with constant current and constant voltage operation. Features 300mA max output current and 57V max output voltage, delivering up to 17W of power. Operates from 7V to 60V input voltage with 97% efficiency. Supports analog and PWM dimming, includes short-circuit protection (SCP), and is rated IP67. Chassis mountable with wire lead termination, suitable for -40°C to 85°C operating temperatures.

MountingChassis Mount

Power17W

Quick Jump:

Technical Specifications

XP Power LDU4860S300-WD technical specifications.

General

Approvals	EN
Dimming	Analog, PWM
Efficiency	97%
Features	SCP
Height	0.49inch
Length	1.25inch
Max Input Voltage	60V
Min Input Voltage	7V
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
Max Output Current	300mA
Max Output Power	17W
Max Output Voltage	57V
Max Power Dissipation	17W
Mount	Chassis Mount
Number of Outputs	1
Output Current	300mA
Output Power	17W
Output Voltage	57V
Package Quantity	15
Ratings	IP67
Reach SVHC Compliant	Unknown
RoHS Compliant	No
Series	LDU48
Termination	Wire Leads
Weight	0.04lb
Width	0.8inch
