Crydom CXE240A5 technical specifications.
| Approvals | UL, CSA, VDE, CE |
| Capacitance | 10pF |
| Package/Case | SIP |
| Current Rating | 5A |
| Input Current | 15mA |
| Input Type | AC |
| Lead Free | Contains Lead |
| Load Current | 5A |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -30°C |
| Max Output Current | 5A |
| Max Output Voltage | 280V |
| Mount | PCB, Through Hole |
| Output Current | 5A |
| Package Quantity | 40 |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | CX |
| Termination | Solder |
| Throw Configuration | SPST |
| Voltage Rating | 280V |
| Width | 7.6mm |
| RoHS | Compliant |
