Crydom H12D4825D technical specifications.
| Approvals | UL, VDE, CE |
| Current Rating | 25A |
| Height | 58.4mm |
| Input Type | DC |
| Lead Free | Lead Free |
| Length | 45.7mm |
| Load Current | 25A |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 25A |
| Max Output Voltage | 530V |
| Mount | Panel, Chassis Mount, Screw |
| Output Current | 250A |
| Package Quantity | 20 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Relay Type | Relay |
| RoHS Compliant | Yes |
| Series | H12D |
| Termination | Screw |
| Throw Configuration | SPST, DPST |
| Voltage Rating (AC) | 530V |
| Width | 21.6mm |
| RoHS | Compliant |
Download the complete datasheet for Crydom H12D4825D to view detailed technical specifications.
