The LS240D8R is a solid state relay with a current rating of 8A and a voltage rating of 280V AC. It features a high input impedance of 270 ohms and a low leakage current of 100uA. The relay is isolated with a voltage rating of 2.5kV and is compliant with UL, CSA, CE, and TUV approvals. It has a maximum operating temperature of 80°C and a minimum operating temperature of -30°C. The LS240D8R is available in a lead-free SIP-4 package and is suitable for through-hole or PCB mounting.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom LS240D8R datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, CSA, CE, TUV |
| Package/Case | SIP |
| Current Rating | 8A |
| Input Current | 15mA |
| Input Impedance | 270R |
| Input Type | DC |
| Isolation Voltage | 2.5kV |
| Lead Free | Lead Free |
| Leakage Current | 100uA |
| Load Current | 8A |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -30°C |
| Mount | Through Hole, PCB |
| Package Quantity | 20 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Relay Type | Relay |
| RoHS Compliant | Yes |
| Series | LS |
| Termination | Solder |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 280V |
| Width | 35.5mm |
| RoHS | Compliant |
