The 26GS22-01-1-16S-C is a 16-position mechanical encoder with 4 channels and 4-bit resolution. It has a through hole mount and operates between -40°C and 85°C. The encoder is not lead-free and is RoHS compliant. It is a mechanical encoder with a detent and is available in a single package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Grayhill 26GS22-01-1-16S-C datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Grayhill 26GS22-01-1-16S-C technical specifications.
| Built in Switch | No |
| Detent | Yes |
| Encoder Type | Mechanical |
| Height | 8.43mm |
| Lead Free | Contains Lead |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole, Panel, PCB |
| Number of Channels | 4 |
| Number of Positions | 16 |
| Orientation | Vertical |
| Package Quantity | 1 |
| Reach SVHC Compliant | No |
| Resolution | 4b |
| RoHS Compliant | Yes |
| Series | 26 |
| Termination | PC Pin |
| RoHS | Compliant |
Download the complete datasheet for Grayhill 26GS22-01-1-16S-C to view detailed technical specifications.
