Hammond 104S technical specifications.
| Current | 6mA |
| Current Rating | 6mA |
| DC Resistance (DCR) | 47R |
| Height | 0.75inch |
| Height - Seated (Max) | 12.19mm |
| Insertion Loss | 1dB |
| Isolation Voltage | 200V |
| Lead Free | Lead Free |
| Length | 18.03mm |
| Max DC Current | 6mA |
| Mount | Through Hole |
| Package Quantity | 1 |
| Packaging | Bulk |
| Primary Impedance | 600R |
| RoHS Compliant | Yes |
| Secondary Impedance | 150R |
| Series | 104 |
| Shielding | Unshielded |
| Termination | PC Pin |
| Weight | 0.05lb |
| Width | 21.84mm |
| RoHS | Compliant |
