Technical Specifications
Hammond 1555EGY technical specifications.
General
Approvals
UL, NEMA
Body Color
Grey
Body Material
ABS
Color
Grey
Depth
2.4inch
Flammability Rating
UL94 HB
Height
2.362inch
Housing Color
Grey
Lead Free
Lead Free
Length
3.543inch
Material
Polystyrene, Plastic, ABS, ACRYLONITRILE BUTADIENE STYRENE
Max Operating Temperature
120°C
Min Operating Temperature
-40°C
Mount
Wall
Package Quantity
1
Ratings
IP66
Reach SVHC Compliant
No
Series
1555
Thickness
0.118inch
Weight
10.582189oz
Width
3.5inch
Compliance
RoHS
Compliant
Datasheet
Hammond 1555EGY Datasheet
Download the complete datasheet for Hammond 1555EGY to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
