Technical Specifications
Hammond 1650WA technical specifications.
General
Current
806mA
Current Rating
806mA
DC Resistance (DCR)
17.19R
Height
113.35mm
Height - Seated (Max)
113.35mm
Insertion Loss
1dB
Length
190.5mm
Max DC Current
806mA
Mount
Chassis Mount
Package Quantity
1
Packaging
Box
Primary Impedance
1.9kR
RoHS Compliant
Yes
Secondary Impedance
4R
Series
A
Termination
Wire Leads
Weight
28lb
Width
111.25mm
Compliance
RoHS
Compliant
Datasheet
Hammond 1650WA Datasheet
Download the complete datasheet for Hammond 1650WA to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
