MountingChassis Mount
Inductance90.95H
Quick Jump:
Technical Specifications
Hammond 1750J technical specifications.
General
DC Resistance (DCR)
185R
Height
3.45inch
Height - Seated (Max)
89.23mm
Inductance
90.95H
Insertion Loss
1dB
Length
103.53mm
Mount
Chassis Mount
Package Quantity
1
Packaging
Box
Primary Impedance
4kR
RoHS Compliant
Yes
Secondary Impedance
4R
Series
1750
Shielding
Unshielded
Termination
Wire Leads
Turns Ratio
31.11:1
Weight
0.625lb
Width
80.52mm
Compliance
RoHS
Compliant
Datasheet
Hammond 1750J Datasheet
Download the complete datasheet for Hammond 1750J to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
