This 400MHz RF amplifier from Infineon features a gain of 21.5dB and a maximum power dissipation of 35mW. It operates from a supply voltage of 2.75V with a current consumption of 5.8mA. The device is packaged in tape and reel format. Note that this component is not radiation hardened and is not RoHS compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Infineon BGA628L7E6327XTMA1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Frequency | 400MHz |
| Gain | 21.5dB |
| Max Power Dissipation | 35mW |
| Noise Figure | 0.75dB |
| Operating Supply Current | 5.8mA |
| Operating Supply Voltage | 2.75V |
| P1dB | -20.5dBm |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| RoHS Compliant | No |
| Test Frequency | 1.57542GHz |
| RoHS | Not CompliantNo |
