The BSZ036NE2LS MOSFET features a maximum operating temperature of 150°C and a minimum operating temperature of -55°C. It has a continuous drain current of 16A and a drain to source voltage of 25V. The device is packaged in a tape and reel format and is compliant with RoHS and Reach SVHC regulations. The MOSFET has a maximum power dissipation of 2.1W and a gate to source voltage of 20V.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Infineon BSZ036NE2LS datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Infineon BSZ036NE2LS technical specifications.
| Continuous Drain Current (ID) | 16A |
| Drain to Source Voltage (Vdss) | 25V |
| Fall Time | 2.2ns |
| Gate to Source Voltage (Vgs) | 20V |
| Halogen Free | Halogen Free |
| Height | 1.1mm |
| Input Capacitance | 1.2nF |
| Lead Free | Lead Free |
| Length | 3.4mm |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Power Dissipation | 2.1W |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Rds On Max | 3.6mR |
| Reach SVHC Compliant | Yes |
| RoHS Compliant | Yes |
| Series | OptiMOS™ |
| Turn-Off Delay Time | 15ns |
| Turn-On Delay Time | 3.3ns |
| Width | 3.4mm |
| RoHS | Compliant |
