The BTS716G is a 4-channel driver from Infineon with a maximum operating temperature of 150°C and a minimum operating temperature of -40°C. It features a maximum output current of 6.5A and a maximum power dissipation of 3.6W. The device is packaged in a SOIC SOP20 package and is RoHS compliant. It has a maximum supply voltage of 40V and a minimum supply voltage of 5.5V.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Infineon BTS716G datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SOIC |
| Drain to Source Voltage (Vdss) | 40V |
| Halogen Free | Halogen Free |
| Lead Free | Lead Free |
| Length | 12.8mm |
| Load Current | 2.6A |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 6.5A |
| Max Power Dissipation | 3.6W |
| Max Supply Voltage | 40V |
| Min Supply Voltage | 5.5V |
| Number of Channels | 4 |
| Number of Outputs | 4 |
| On-State Resistance | 110mR |
| Output Current per Channel | 2.6A |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| RoHS Compliant | Yes |
| Supply Current | 500uA |
| Thickness | 2.65mm |
| Width | 7.6mm |
| RoHS | Compliant |
