The FP40R12KE3 is an IGBT power module from Infineon with a collector emitter breakdown voltage of 1.2kV and a maximum collector current of 55A. It has a power dissipation of 200W and is packaged in an EconoPIM2 module. The module is designed to operate within a temperature range of -40°C to 125°C. It is compliant with RoHS regulations and is not SVHC compliant. The module measures 107.5mm in length, 45mm in width, and 17mm in height.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Infineon FP40R12KE3 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Infineon FP40R12KE3 technical specifications.
| Package/Case | Module |
| Collector Emitter Breakdown Voltage | 1.2kV |
| Collector Emitter Saturation Voltage | 1.8V |
| Collector Emitter Voltage (VCEO) | 1.2kV |
| Height | 17mm |
| Length | 107.5mm |
| Max Collector Current | 55A |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 210W |
| Mount | PCB, Screw |
| Power Dissipation | 200W |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Width | 45mm |
| RoHS | Compliant |
