The IPD90N03S4L03ATMA1 is a N-Channel MOSFET with a continuous drain current of 90A and a drain to source voltage of 30V. It has a fall time of 7ns and a gate to source voltage of 16V. The device is halogen free and has a maximum operating temperature of 175°C. It is also RoHS compliant and has a lead free package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Infineon IPD90N03S4L03ATMA1 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Infineon IPD90N03S4L03ATMA1 technical specifications.
| Continuous Drain Current (ID) | 90A |
| Drain to Source Voltage (Vdss) | 30V |
| Fall Time | 7ns |
| Gate to Source Voltage (Vgs) | 16V |
| Halogen Free | Halogen Free |
| Lead Free | Contains Lead |
| Max Dual Supply Voltage | 30V |
| Max Operating Temperature | 175°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| RoHS Compliant | Yes |
| Turn-Off Delay Time | 37ns |
| Turn-On Delay Time | 9ns |
| RoHS | Compliant |
Download the complete datasheet for Infineon IPD90N03S4L03ATMA1 to view detailed technical specifications.
