EP3C10U256C8N

Name: EP3C10U256C8N Intel
Brand: Intel
SKU: EP3C10U256C8N

Field Programmable Gate Array, 10320 CLBs, 472.5MHz, 10320-Cell, CMOS, PBGA256, 14 X 14 MM, 2.20 MM HEIGHT, 0.80 MM PITCH, LEAD FREE, UFBGA-256

Frequency402MHz

PackageLFBGA

MountingSurface Mount

Quick Jump:

Intel EP3C10U256C8N technical specifications.

Package/Case	LFBGA
Frequency	402MHz
Max Frequency	315MHz
Max Operating Temperature	85°C
Memory Size	423936b
Min Operating Temperature	0°C
Max Supply Voltage	1.25V
Min Supply Voltage	1.15V
Mount	Surface Mount
Number of I/Os	182
Number of Logic Blocks (LABs)	645
Number of Logic Elements/Cells	10320
Number of Macrocells	10320
Operating Supply Voltage	1.2V
Package Quantity	119
Packaging	Tray
Radiation Hardening	No
RAM Size	423936b
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Series	Cyclone III
Speed Grade	8
Termination	SMD/SMT
