The 74HC165N is an 8-bit 8-stage serial-in parallel-out shift register from NXP. It operates over a temperature range of -40°C to 125°C and is supplied with a voltage between 2V and 6V. The device is available in a DIP16 package and is compliant with RoHS regulations. The 74HC165N is a logic IC designed for use in digital circuits, featuring 8 stages of serial-in parallel-out operation.
PackageDIP
Quick Jump:
Technical Specifications
NXP 74HC165N technical specifications.
General
| Package/Case | DIP |
| Lead Free | Lead Free |
| Logic Function | Shift Register |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 6V |
| Min Supply Voltage | 2V |
| Number of Bits | 8 |
| Number of Circuits | 8 |
| Number of Elements | 1 |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
Compliance
| RoHS | Compliant |
Datasheet
NXP 74HC165N Datasheet
Download the complete datasheet for NXP 74HC165N to view detailed technical specifications.
