The BGA3031J is a VQFN packaged RF amplifier with a maximum operating frequency of 85MHz and a gain of 34dB. It can dissipate a maximum power of 1.625W and operates within a temperature range of -65°C to 150°C. The amplifier is RoHS compliant and is available in a tape and reel packaging format with 6000 units per package. It features gold and silver contact plating and is suitable for surface mount applications.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the NXP BGA3031J datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | VQFN |
| Contact Plating | Gold, Silver |
| Frequency | 85MHz |
| Gain | 34dB |
| Max Frequency | 85MHz |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -65°C |
| Max Power Dissipation | 1.625W |
| Max Supply Current | 325mA |
| Max Supply Voltage | 5V |
| Mount | Surface Mount |
| Noise Figure | 3.5dB |
| Operating Supply Current | 325mA |
| Package Quantity | 6000 |
| Packaging | Tape and Reel |
| RoHS Compliant | Yes |
| RoHS | Compliant |
