Unidirectional TVS Diode for circuit protection, featuring a 48pF capacitance and 27V clamping voltage. This surface mount component offers a reverse standoff voltage of 18V and a maximum surge current of 700mA. Operating across a wide temperature range from -65°C to 150°C, it is supplied in a 6-pin TSOP package. The device is lead-free and RoHS compliant.
Sign in to ask questions about the NXP BZA418A,165 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
NXP BZA418A,165 technical specifications.
| Capacitance | 48pF |
| Package/Case | TSOP |
| Clamping Voltage | 27V |
| Clamping Voltage-Max | 27V |
| Depth | 1.7mm |
| Diode Type | ZENER |
| Direction | Unidirectional |
| Lead Free | Lead Free |
| Leakage Current | 75nA |
| Length | 3.1mm |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -65°C |
| Max Surge Current | 700mA |
| Mount | Surface Mount |
| Number of Channels | 4 |
| Number of Elements | 4 |
| Number of Unidirectional Channels | 4 |
| Operating Supply Voltage | 18.9V |
| Package Quantity | 10000 |
| Packaging | Tape and Reel |
| Peak Pulse Current | 700mA |
| Peak Pulse Power | 19.6W |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Radiation Hardening | No |
| Reverse Standoff Voltage | 18V |
| RoHS Compliant | Yes |
| Termination | SMD/SMT |
| RoHS | Compliant |
