Technical Specifications
NXP MPC8271VRTIEA technical specifications.
General
Package/Case
BGA
Data Bus Width
32b
Frequency
400MHz
Halogen Free
Halogen Free
Lead Free
Lead Free
Max Frequency
400MHz
Max I/O Voltage
1.5V
Max Operating Temperature
105°C
Memory Size
16KB
Min Operating Temperature
0°C
Mount
Surface Mount
Number of Cores
1
Number of I/Os
24
Number of Programmable I/O
14
Operating Supply Voltage
1.5V
Package Quantity
40
Packaging
Tray
Radiation Hardening
No
RAM Size
20KB
RoHS Compliant
Yes
Series
MPC82xx
Weight
0.154237oz
Compliance
RoHS
Compliant
Datasheet
NXP MPC8271VRTIEA Datasheet
Download the complete datasheet for NXP MPC8271VRTIEA to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
