NXP PMF780SN115 technical specifications.
| Package/Case | SC |
| Continuous Drain Current (ID) | 570mA |
| Drain to Source Breakdown Voltage | 60V |
| Drain to Source Resistance | 920mR |
| Drain to Source Voltage (Vdss) | 60V |
| Drain-source On Resistance-Max | 920MR |
| Fall Time | 4ns |
| Gate to Source Voltage (Vgs) | 20V |
| Input Capacitance | 23pF |
| Lead Free | Lead Free |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Power Dissipation | 560mW |
| Mount | Surface Mount |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Polarity | N-CHANNEL |
| Power Dissipation | 560mW |
| Radiation Hardening | No |
| Rds On Max | 920mR |
| Series | TrenchMOS™ |
| Turn-Off Delay Time | 5ns |
| Turn-On Delay Time | 2ns |
| RoHS | Compliant |
